Time Relay GRT8-A2 Delay On Timer Switch, 16A 230V Adjustable Timer Relay in Din Rail for Industrial Grade Waterproof and Dustproof Design
Product details
| Management number | 218152107 | Release Date | 2026/05/03 | List Price | $8.80 | Model Number | 218152107 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- FUNCTION& APPLICATION: time delay relay , preset machine start time. It has a wide delay setting range of 0.1 seconds to 10 days, a wide operating voltage of GRT8-A2 AC230V (50-60Hz), and a rated current of 16A. Output contact: 2SPDT (2NO 2NC). This timer delay relay module on relay can be used in industrial equipment, lighting, manufacturing industries to precisely control the delay time for changing lighting, heating, motors, machines, etc
- INDICATOR BUTTON: The working status of grt8-a2 ac230v delay on time relay is indicated by the LED indicator light: the green LED indicator is always on (power on), the green LED indicator is off (power abnormality); the red LED indicator flashes (indicating the start of work), when the relay delay function is working, the red LED indicator is always on, and the red LED indicator is off (indicating the stop of work). If you want to set a 5-seconds delay, adjust the first knob of this delay on time relay to 10s and turn the second knob to 50%, then the terminal will start work in 5 seconds. Please check the instructions and videos before operation, which can help you better use the relay
- Model of GRT8 Time Relay: 1. GRT8-A: Delay ON time relay; GRT8-B: Delay Off time relay; GRT8-S：Asymmetric Cycle Timer Relay (OFF-ON-OFF and ON-OFF-ON, the duration of OFF and ON can be set); GRT8-M: Multi functional time relay, covering GRT8 series A (delayed power on), B (delayed disconnection), C (cyclic delay: OFF-ON-OFF), D (cyclic delay: ON-OFF-ON），and function E as shown in the figure, F,G,H,I,J
- Designed time relay: The GRT8 series delay relay has a sealed housing made of industrial grade ABS plastic to protect internal components. Its sturdy design can accompany your expensive equipment for a longer period of time and complies with UL standards CE、CB、RoHS。 The Din rail delay timer relay measures 2.88 inches x 3.68 inches x 0.9 inches, weighs approximately 3.3 ounces, and is installed on a 35mm Din rail. Durable, easy to install, portable and compact
- WORRY FREE AFTER-SALES SERVICE: We provides a 30 day no reason return and a 3-year warranty for this product. If you have any questions about installation or use, or if you encounter any problems during use, please feel free to reach up to us at any time
| Model | GRT8-A2 AC230V |
|---|---|
| Brand Name | IGEYAPA |
| Item Weight | 3.2 ounces |
| Part Number | GRT8-A2 AC 230V |
| Contact Type | Normally Open |
| Manufacturer | IGEYAPA |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 16 Amps |
| Contact Material | Copper |
| Specification Met | CE, RoHS |
| Included Components | 1 Timer Relay*1 Using Manual |
